Highlights
handy and lightweight hand welding machine
optimal for car upholsterers and tarpaulin processors
cost-effective and user-friendly welding device
has a fixed heating stage with additional cold stage
Description
The cost-effective, handy and uncomplicated hand welding device for the tarpaulin industry.
In the PVC tarpaulin industry, this device can be regarded as a low-cost tarpaulin welding tool because it only has one fixed heating stage and an additional cold stage.
Thanks to the device’s convenient handle and renowned industrial quality, the tarpaulin manufacturer has the ability to weld his PVC material with constant heating power and also receives all the benefits of professional and fatigue-free welding
The Robust-L type’s collector carbons can be easily changed from the outside – without opening the unit, as well as with FORSTHOFF manual welding units. Our carbon brushes have a 1,500-hour carbon life and a shut-off mechanism, so when the carbon brushes are exhausted, the motor shuts off to prevent damage to the collector and subsequent repair cost
The heating power of the device is available in 900W and 1500W versions in order to accommodate the 20 or 40 mm wide slip-on nozzles demanded by the tarpaulin manufacturer.
Technical specifications
Voltage:
230V; 120V
Power:
depending on the attachment nozzle 900W 230V or 1500W 230V; 1300W 120V
Frequency:
50/60 Hz
Temperature:
up to max. 700°C;
adjustable in maximum power
Air flow:
300 l/min
Dimensions:
Ø 320 x 95 mm, handle Ø 48 mm
Weight:
1.2 kg with 3m connecting cable
Conformity mark
CE; EAC
Protection class:
II /
Accessories
- Nozzles
- Pressure rollers
- General Accessories
- Tool case
- Heating elements
Item no. 4002
Wide slot nozzle 20mm
Item no. 4003
Wide slot nozzle 40mm
Item no. 6991
28mm PTFE pressure roller with ball bearings
Item no. 6995
45mm 45° silicone pressure roller with ball bearings
Item no. 7000
45mm silicone pressure roller, double arm
Item no. 6992
45mm PTFE pressure roller with ball bearings
Item no. 6996
80mm silicone pressure roller with ball bearings
Item no. 7001
45mm silicone pressure roller, single arm
Item no. 6993
Brass penny roller 30mm
Item no. 6997
45mm silicone pressure roller with ball bearings, single arm
Item no. 7002
80mm silicone pressure roller
Item no. 6994
28mm silicone pressure roller with ball bearings
Item no. 6998
45mm silicone pressure roller with ball bearings, double arm
Item no. 7006
45mm 45° silicone pressure roller
Item no. 5021
Trimming guide
Item no. 7018
Trimming knife
Item no. 7010
Cutter
Item no. 7020
Seam trimmer
Item no. 7011
Hand groover
Item no. 7014
Seam probe tester
Item no. 7025
Tool case
Item no. 2007
Heating element 230V 1500W
Item no. 4011
Insulating sleeve
Item no. 2004
Heating element 230V 900W
Item no. 2009
Heating element 120V 1650W
Application areas
Car upholstery
Tarpaulin manufacturer
Tent manufacturer
Cover tarpaulins
Advertising banner manufacturer
